Stratasys ProAero™
For office environment 3D printing
The ProAero is compatible with Stratasys J3/J5 Series, and the Stratasys Origin One for office environment 3D printing. Use the ProAero to ensure that clean air and low noise pollution is always maintained in the workplace.
The unique filtration system is designed to block out both the noise and odor that can sometimes be irritating or unpleasant during the printing process, especially if you’re working inside of a small space with poor ventilation.
HEPA Filter
Small Footprint
3D Printer Compatability
Stratasys J3/J5 series, and Origin One
| Stratasys ProAero Product Specifications | |
|---|---|
| Capacity | 75 m³/h (44CFM) |
| Airflow/Pressure | 150m3/h (88CFM) |
| Poids | 10.5 kg (23.1 lbs) |
| Motor | Centrifugal |
| Fan Output | 100 W |
| Electrical Supply | 115-230 V |
| Frequency | 50/60Hz |
| Full Load Current | 2.0 A |
| Noise Level | Below 57 dBA (at typical operating speed) |
| Taille | 413 x 298 x 283 mm; 16.3 x 11.7 x 11.1 in |
| Température | +5˚C to +40˚C; +41˚F to +104˚F |
| Humidité | Max 80% relative humidity (RH) up to 31˚C; Max 50% RH at 40˚C |
| Filter Type | Filter Construction | Filter Efficency |
|---|---|---|
| Pre Filter | Pad | F7 (96% @ 2 microns) |
| Combined Filter HEPA | Maxipleat Construction with Webbing Spacers | 99.997% @ 0.3 microns |
| Carbon | Granules | Activated |
Stratasys ProAero+
For industrial and enterprise level 3D printing
The ProAero+ is compatible with the Stratasys J8/J7 and Connex series printers for industrial and enterprise level 3D printing. Use ProAero+™ with your market leading Stratasys J8 Series PolyJet 3D printers and you can rest assured that no impurities will make their way back inside your system; clean air is maintained throughout the 3D printing process, even at Enterprise level.
As contaminated air enters the drop out chamber, it is pulled through a HEPA filter ensuring that clean air is maintained throughout the 3D printing process.
HEPA Filter
Advanced carbon filter (ACF) technology
Multi voltage sensing (MVS) unit
3D Printer Compatability
Stratasys J7/J8 series
| Spécifications des produits | UE | US |
|---|---|---|
| Dimensions (HxWxD) without silencer box | 625 x 385 x 525 mm | 24.60 x 15.16 x 20.67 in |
| Cabinet construction | Powder coated mild steel | Powder coated mild steel |
| Airflow / pressure | 380m3/hr / 96mbar | 223cfm / 96mbar |
| Electrical data | 90 – 257v Single-phase 1~ 50/60Hz Full load current: 12.5 amps/ 1.1kw | 90 – 257v Single-phase 1~ 50/60Hz Full load current: 12.5 amps/ 1.1kw |
| Noise level | < 65dBA (at typical operating speed) | < 65dBA (at typical operating speed) |
| Poids | 51kgs | 113lbs |
| HEPA / gas filter specifications | |
|---|---|
| Treated activated carbon | 20kgs (44 lbs) |
| Filter media | Borosilicate |
| Filter housing | Zintec mild steel |
| Surface media area | 3.5m² approx (37.66 ft²) |
ProAero+ features:
- VOC gas sensor (Volatile Organic Compound)
- VOC signal
- Extended life carbon for low cost of ownership
- Auto sensing voltage (90-257v) for global use
- Low noise level
- Specially treated carbon for safe containment of print fumes
- Compact size enables extraction unit to be positioned within the printer footprint
- Small footprint
- Powder coated for durability
- Castors for portability
- Filter change indicator
- Digital speed control
- Filter change signal
ProAero Benefits
Benefits of using a Stratasys air filtration system
Creates a Safe Environment
Maintaining a safe and clean working environment is always a top priority when working with 3D printing materials. Stratasys ProAero™ and ProAero+™ extractor units ensure clean air is maintained throughout the printing process, with unique filtration systems that meet airborne emissions standards and optimize productivity.
HEPA Filter
The intuitive, compact design and built-in HEPA filter ensures any particles or fumes generated from your print will be captured and cleaned before being recirculated back into your production environment. Low noise, low power consumption, integral speed control and easy integration with all compatible Stratasys PolyJet Printers – what more could you possibly need?
Is the Stratasys ProAero Air Extractors right for you?
