SOLIDWORKS Dimension

How to apply All Uppercase to SOLIDWORKS Dimensions & Hole Callouts

In SOLIDWORKS 2020, you can set the dimension characters or hole callouts to show as all uppercase characters in the graphics area for drawings. This can be done for a single dimension by selecting that dimension, going to dimension property manager, and clicking on All…

Read More...

Aligning linear diameter dimensions in SOLIDWORKS drawings

Diameter dimensions can be modified to display as linear dimensions if needed. To convert the diameter dimension into linear follow these steps: Step 1: Right click the Diameter dimension > Display options > Display as linear OR this can also be done by selecting the…

Read More...

SOLIDWORKS angle dimension between 3 points

What if we need an angle dimension in a sketch, but one of the entities is not a line (perhaps it is a spline or arc instead)?  The answer, we can take the angle between 3 endpoints! In this sketch on the right plane (which…

Read More...

How to adjust SOLIDWORKS Spin Box Increment Values Locally & Globally

Upon editing a dimension value in SOLIDWORKS, you can use the SOLIDWORKS spin box instead of typing in numbers. The middle mouse wheel or clicking on the little up/down arrows on the right side of the dimension box could be used to fine-tune a dimension…

Read More...

Use the SOLIDWORKS Spin Box to Increase/Decrease Dimensions in Increments

The SOLIDWORKS Spin Box is the small thumbwheel at the bottom of the Modify dialog box.  This can be used to incrementally increase or decrease a dimension value.  If the dimension is bounded (i.e. an angle between 0 and 90deg) you may see a slider…

Read More...

Select the outside of an Arc rather than the center when adding a dimension in SOLIDWORKS

When adding arc dimensions, you should always select the actual arc rather then the centre point. Doing so will give you more options for the dimension. As you can see in the image below, under the leaders tab after selecting a dimension, we can select…

Read More...

Is your SOLIDWORKS Sketch Dimension difficult to Delete or Modify?

To delete a SOLIDWORKS Sketch Dimension you typically select the dimension and hit Delete.  To edit the value of the dimension you would double-click on the value to open the Modify dialog. Are you having difficulties performing these steps?  See if you have the option…

Read More...

Dimensioning in Style (with SOLIDWORKS Dimension Styles)

Often times, SOLIDWORKS Dimension Styles are passed without notice because it is quite easy to get the job done without using them. However, they can be used for dimensions that have very common notes attached to them. For instance, when I used to design automated…

Read More...

SOLIDWORKS Arc Dimension

Sometimes you need to add a SOLIDWORKS Arc Length Dimension.  This can be done in both Sketch and Drawing environments.  The Smart Dimension tool, with the correct selections, is used to create a SOLIDWORKS Arc Dimension. Arc Dimension in a Sketch Within the Sketch environment, the…

Read More...
